Max. permissible load of the shelves

• Inside the oven
  45 kg/oven
• Per shelves
  25 kg

Electric parameters – mains 50/60 Hz

• Nominal voltage
  230 V
• Mains 50/60 Hz
  1,2 kW
• Current
  5,2 A
• Input in stand by mode
  5 W

Vacuum connection

• Feedthrough needle valve for inert gas or air
  8 mm
• Measuring acces (ISO KF)
  40 mm
• Vacuum connection measuring DN (ISO KF) Including hose end Ø 12 mm
  16 mm

Heat radiation

• At 100 °C
  260 W
• At 200 °C
  520 W

Time of rise onto 98 % voltage 230 V – (shelves pressure 5–10 mbar)

• Onto temp 100 °C
  140 min

Time of rise onto 98 % voltage 230 V – (Al shelves pressure 5–10 mbar)

• Onto temp 100 °C
  65 min
• Onto temp 200 °C
  85 min

Temp. deviations acc. to DIN 12 880 Part 2 from working temp – ss shelves pressure 5–10 mbar**

• In time to:
  1 ± °C
• In space, temperature 100 °C do:
  10 ± °C
• In space, temperature 200 °C do:
  23 ± °C

Temp. deviations acc. to DIN 12 880 Part 2 from working temp – Al shelves pressure 5–10 mbar**

• In time to:
  0,4 ± °C
• In space, temperature 100 °C do:
  2 ± °C
• In space, temperature 200 °C do:
  6 ± °C

Working temperature (regulation start)

• From 5 °C over ambient temp to :
  200 °C

External dimensions (including door and handle)

• Depth:
  560 mm
• Width:
  620 mm
• Heights(incl. foots):
  910 mm

Usefull dim. of shelf

• Width × Depths
  340 × 296 mm

Minimal Shelves distance

• Height
  43 mm

Tray

• Number:
  2 pcs
• Racks max. :
  7 pcs

Interior of stainless steel material No. 1.4571

• Volume :
  55 l
• Depth:
  320 mm
• Width:
  400 mm
• Height:
  430 mm
