(STIRRING DRYBATH 8-250 ERL) Stirring and heating
2mag stirring-heating block combination with 8 stirring positions, 8 bore holes, ø 87.2 mm, depth 78 mm, suitable for 250 ml Erlenmeyer flasks.
Stirring – wear- and maintenance-free thanks to inductive 2mag magnetic drive, wide speed range from 100 to 2,000 rpm with smooth operation even at low speeds, 100% synchronous rotation, 10-stage power setting for high performance with viscous stirring quantities and reduced power for heat-free continuous operation, digital display for speed, power and temperature setting, SoftStart for reliable catching/centering and safe acceleration of the stirring bar.
Heating – Massive heating block made of resistant aluminium alloy, PTFE-coated for increased chemical resistance and easier cleaning, contact adapters for an optimal heat transfer, lowest possible temperature gradient inside the stirring vessels, integrated electrical heater, maximum heating temperature +200 °C. PowerDetect for automatic compensation of physically induced stirring power losses, which can be up to 40% at high temperatures, smallest possible temperature gradient in the sample vessels due to low-loss, all-round energy transfer to the vessel.
Specially made insulated stainless steel frame for energy- and time saving heating process, additionally for a homogenous temperature distribution and protection against accidental contact, independent over-temperature protection inside the plate.
Inclusive separate control unit for operation of magnetic stirrer and integrated heater, for long-term protection of the electronics against aggressive liquids and gases as well as thermal influences, stainless steel housing. Includes 8 contact sleeves for optimized heat transfer.
Stirring-heating block with 8 positions wirbel_mini Fast heating-up up to 200°C Stirring speed from 100 up to 2,000 rpm Borehole diameter 87.2 mm For 250 ml Erlenmeyer flasks Energy-saving Insulated frame Durable quality Developed and made in Germany
Product Details
| type | STIRRING DRYBATH 8-250 ERL |
| Stirring points | 8 |
| Stirring point spacing | 100 mm/140 mm |
| Block bores Ø/D | Ø 87.2 / 78 mm |
| Stirring volume/stirring point | 1 – 250 ml |
| Stirring power (max.) | 40 W |
| Power setting | 10 – 100% (10-stage) |
| Temperature range | +40 °C to +200 °C |
| Speed range | 100 – 2,000 rpm |
| Operating voltage | 230 V |
| Heating output (max.) at 230 V mains voltage | 1.150 W |
| Dimensions (WxDxH) | 335 x 515 x 150 mm |
| Protection class | IP20 |
| Shipping weight (gross) | approx. 40 kg |
| Order no. | 63825 |
